型號

筒體直徑×筒體總長（m)

筒體轉速（r/min)

筒體容積（m3)

參考裝球量

生產能力（t/h）

傳動電機

外型尺寸

型號

功率(KW)

（長×寬×高）

ZTMY/G0909

0.9×0.9

39.7

0.45

0.9

0.22-1.07

Y160L-8

7.5

3245×1828×1570

ZTMY/G0912

0.9×1.2

0.6

1.2

0.29-1.43

Y160L-8

7.5

3545×1828×1570

ZTMY/G0918

0.9×1.8

40

0.9

1.5

0.44-2.14

Y180L-8

11

4210×1858×1570

ZTMY/G0921

0.9×2.1

1.05

1.8

0.51-2.5

Y180L-8

11

4510×1858×1570

ZTMY/G0924

0.9×2.4

40

1.2

2.1

1.58-2.86

Y200L-8

15

4965×1933×1570

ZTMY/G0930

0.9×3.0

1.5

2.5

0.73-3.6

Y225S-8

18.5

5610×1968×1570

ZTMY/G1212

1.2×1.2

30.8

1.1

1.8

0.2-2.9

Y225S-8

18.5

3990×2200×1855

ZTMY/G1216

1.2×1.6

1.5

2.5

0.3-4

Y225S-8

18.5

4390×2200×1855

ZTMY/G1220

1.2×2.0

31.3

1.85

3.1

0.37-4.9

Y225M-8

22

4885×2200×1855

ZTMY/G1224

1.2×2.4

2.2

3.6

0.4-5.8

Y280S-8

37

5135×2240×1855

ZTMY/G1228

1.2×2.8

2.6

4.3

0.5-6.9

Y280S-8

37

6008×2530×1855

ZTMY/G1236

1.2×3.6

31.3

3.2

5.2

0.6-7.9

Y280M-8

45

6673×2530×1855

ZTMY/G1240

1.2×4.0

3.7

6.1

0.7-9

Y280M-8

45

7346×2530×1855

ZTMY/G1245

1.2×4.5

4.2

6.8

0.8-9.8

Y280S-8

75

7846×2530×1855

ZTMY/G1521

1.5×2.1

31.5

3.15

4.9

2-6.2

YR280M-8

45

5858×2950×2490

ZTMY/G1530

1.5×3.0

30.5

4.5

7.5

2.8-9

YR280M-8

75

7046×3098×2490

ZTMY/G1536

1.5×3.6

5.5

8.8

3.5-11.1

JR117-8

80

7862×3147×2490

ZTMY/G1557

1.5×5.7

30.5

8.8

14.5

6.4-34.6

JR126-8

110

9210×3147×2490

ZTMY/G18330

1.83×3.0

27

6.9

11.8

4-20

JR127-8

130

7862×3412×3070

ZTMY/G18335

1.83×3.5

8.2

13.6

4.9-26.9

JR127-8

130

8062×3412×3070

ZTMY/G18340

1.83×4.0

9.1

15

5.9-32.5

JR128-8

155

8662×3412×3070

ZTMY/G18364

1.83×6.4

27

14.5

23.2

12.5-47.8

JR138-8

245

11709×3582×3070

ZTMY/G2118

 2.1x1.8

23.9

 5.4

8.9

4.1-23.4

 JR126-8

110

6842×3882×3370

ZTMY/G2124

2.1×2.4

23.9

7.6

12

5.7-33

JR127-8

130

7442×3882×3370

ZTMY/G2130

2.1×3.0

23.9

9.5

15

6.7-37.3

JR128-8

155

8132×3932×3370

ZTMY/G2136

2.1×3.6

23.9

11.5

18

8.1-44.9

JR136-8

180

8752×4047×3370

ZTMY/G2150

2.1×5.0

15.9

25

11.9-68.8

JR138-8

245

10302×4047×3370

ZTMY/G2160

2.1×6.0

23.9

18.9

30.2

13.9-72.8

JR138-8A

280

11553×4047×3370

ZTMY/G2430

2.4×3.0

23.4

11.8

21.7

7.2-92

JR147-8

260

9728×4905×4320

ZTMY/G2442

2.4×4.2

16.5

31

11-129

JR148-8

310

10928×5274×4320

ZTMY/G2480

2.4×8.0

23.4

33.2

53

15-110

JR1510-8

500

14358×5274×4320

ZTMY/G2721

2.7×2.1

22.05

10.7

17.7

7-84.6

JR1410-8

280

8954×5453×4405

ZTMY/G2724

2.7×2.4

12.3

20.2

8-96.7

JR1410-8

280

9254×5453×4405

ZTMY/G2728

2.7×2.8

20.7

14.3

23.6

9.3-112.8

JR157-8

320

9474×5543×4405

ZTMY/G2736

2.7×3.6

21.8

18.4

30.3

12-135

JR158-8

380

10274×5543×4405

(JR158-8)

ZTMY/G2736

TDMK400-32/2150

400

9511×5796×4674

(TDMK400)

ZTMY/G2740

2.7×4.0

21.8

20.4

33.7

13.3-161

YR500-8

400

11469×5767×4405

(YR500-8)

ZTMY/G2740

TDMK400-32/2150

400

9911×5796×4674

(TDMK400)

ZTMY/G2742

2.7×4.2

21.8

21.5

35.4

14-161

YR500-8

400

11669×5767×4405

(YR500-8)

ZTMY/G2742

TDMK400-32/2150

400

10111×5796×4674

(TDMK400)

ZTMY/G2745

2.7×4.5

21.8

23

37.9

15-161

YR500-8

400

11969×5767×4405

(YR500-8)

ZTMY/G2745

TDMK400-32/2150

400

10411×5796×4674

(TDMK400)

ZTMY/G2760

2.7×6.0

21.8

30.7

50

18-175

TDMK630-32/2150

630

13956×5767×4674

(TDMK630)

ZTMY/G2760

YR630-8

630

14202×5796×4674

(YR630-8)

ZTMY/G3236

3.2×3.6

18.5

26.5

46

37-136

TDMK630-36/2600

630

10082×6805×5383

ZTMY/G3240

3.2×4.0

18.5

28.3

52

40-152

TDMK630-36/2600

630

10482×6805×5383

ZTMY/G3245

3.2×4.5

18.5

31.8

58

46-170

TDMK710-36/2600

710

10982×6805×5383

ZTMY/G3254

3.2×5.4

18.5

38.1

61

47-180

TDMK800-36/2600

800

12310×7153×5383

ZTMY/G3636

3.6×3.6

18

32.7

67.7

60-180

TDMK800-36/2600

800

11002×7153×5550

ZTMY/G3645

3.6×4.5

18

40.8

84.5

120-220

TDMK1000-36/2600

1000

11902×7153×5550

ZTMY/G3680

3.6×8.0

18

73.2

117.1

120-230

TDMK1600-36/2600

1600

15402×7153×5550
